Spiral Binding protects and bundles wires, cables and tubes. This versatile form of protection can be fitted to cables and tubes in place. Spiral Binding also allows wires to be broken out any point whilst creating a homogenous assembly that can follow any route.
There are 6 different materials to choose from which range standard polyethylene for general panel building to PTFE for very aggressive environments.
A specially formulated UV resistant version is also available. NFP-UV allows the user to securely manage wire and cable outside.
|
|
| Material Specification - N |
| Material |
Nylon 6 |
| Continuous Operating Temperature |
-60°C to +95°C |
| Intermittent Temperature |
130°C |
|
| Material Specification - P |
| Material |
PTFE |
| Continuous Operating Temperature |
-60°C to +260°C |
| Intermittent Temperature |
350 °C |
|
| Material Specification - LFPS |
| Material |
Polyolefin |
| Continuous Operating Temperature |
-60°C to 120°C |
| Intermittent Temperature |
2 40°C |
| Flame Retardancy UL94 |
VO |
| Halogen Content |
Zero |
|
| Material Specification - NFP |
| Material |
Polythene |
| Continuous Operating Temperature |
-60°C to +90°C |
| Intermittent Temperature |
120°C |
|
| Material Specification - FRP |
| Material |
Flame Retarded Polythene |
| Continuous Operating Temperature |
-60°C to +70°C |
| Intermittent Temperature |
120°C |
| Flame Retardancy UL94 |
V2 |
|
